    ASTM A106 Dimensional Table

    Pipe Size Schedule Wall Thickness Weight/ft OD ID
    1/8" 40 0.068 0.25 0.405 0.269
    1/8" 80 0.095 0.32 0.405 0.215
    1/4" 40 0.088 0.43 0.54 0.364
    1/4" 80 0.119 0.54 0.54 0.302
    3/8" 40 0.091 0.57 0.675 0.493
    3/8" 80 0.126 0.74 0.675 0.423
    1/2" 40 0.109 0.85 0.84 0.622
    1/2" 80 0.147 1.09 0.84 0.546
    1/2" 160 0.188 1.31 0.84 0.464
    1/2" XXH 0.294 1.71 0.84 0.252
    3/4" 40 0.113 1.13 1.05 0.824
    3/4" 80 0.154 1.47 1.05 0.742
    3/4" 160 0.219 1.94 1.05 0.612
    3/4' XXH 0.308 2.44 1.05 0.434
    1" 40 0.133 1.68 1.315 1.049
    1" 80 0.179 2.17 1.315 0.957
    1" 160 0.25 2.84 1.315 0.815
    1" XXH 0.358 3.66 1.315 0.599
    1-1/4" 40 0.14 2.27 1.66 1.38
    1-1/4" 80 0.191 3 1.66 1.278
    1-1/4" 160 0.25 3.76 1.66 1.16
    1-1/4" XXH 0.382 5.21 1.66 0.896
    Pipe Size Schedule Wall Thickness Weight/ft OD ID
    1-1/2" 40 0.145 2.72 1.9 1.61
    1-1/2" 80 0.2 3.63 1.9 1.5
    1-1/2" 160 0.281 4.86 1.9 1.338
    1-1/2" XXH 0.4 6.41 1.9 1.1
    2" 40 0.154 3.65 2.375 2.067
    2" 80 0.218 5.02 2.375 1.939
    2" 160 0.343 7.46 2.375 1.689
    2" XXH 0.436 9.03 2.375 1.503
    2-1/2" 40 0.203 5.79 2.875 2.469
    2-1/2" 80 0.276 7.66 2.875 2.323
    2-1/2" 160 0.375 10.01 2.875 2.125
    2-1/2" XXH 0.552 13.7 2.875 1.771
    3" 40 0.216 7.58 3.5 3.068
    3" 80 0.3 10.25 3.5 2.9
    3" 160 0.438 14.32 3.5 2.624
    3" XXH 0.6 18.58 3.5 2.3
    3-1/2" 40 0.226 9.11 4 3.548
    3-1/2" 80 0.318 12.51 4 3.364
    3-1/2" XXH 0.636 22.87 4 2.728
    Pipe Size Schedule Wall Thickness Weight/ft OD ID
    4" 40 0.237 10.79 4.5 4.026
    4" 80 0.337 14.98 4.5 3.826
    4" 120 0.438 19 4.5 3.624
    4" 160 0.531 22.51 4.5 3.438
    4" XXH 0.671 27.54 4.5 3.18
    5" 40 0.258 14.62 5.563 5.047
    5" 80 0.375 20.78 5.563 4.813
    5" 120 0.5 27.04 5.563 4.563
    5" 160 0.625 32.96 5.563 4.313
    5" XXH 0.75 38.55 5.563 4.063
    6" 40 0.28 18.97 6.625 6.065
    6" 80 0.432 28.57 6.625 5.761
    6" 120 0.562 36.39 6.625 5.501
    6" 160 0.719 45.35 6.625 5.187
    6" XXH 0.864 53.16 6.625 4.897
    8" 40 0.322 28.55 8.625 7.981
    8" 80 0.5 43.39 8.625 7.625
    8" 120 0.719 60.71 8.625 7.187
    8" XXH 0.875 72.42 8.625 6.875
    8" 160 0.906 74.69 8.625 6.813
    Pipe Size Schedule Wall Thickness Weight/ft OD ID
    10" 40 0.365 40.48 10.75 10.02
    10" 60/XH 0.5 54.74 10.75 9.75
    10" 80 0.594 64.33 10.75 9.562
    10" 100 0.719 77.03 10.75 9.312
    10" 120 0.844 89.29 10.75 9.062
    10" 140/XXH 1 104.13 10.75 8.75
    10" 160 1.125 115.65 10.75 8.5
    12" STD 0.375 49.56 12.75 12
    12" 40 0.406 53.53 12.75 11.938
    12" XH 0.5 65.42 12.75 11.75
    12" 60 0.562 73.16 12.75 11.626
    12" 80 0.688 88.51 12.75 11.374
    12" 100 0.844 107.32 12.75 11.062
    12" 120/XXH 1 125.49 12.75 10.75
    12" 140 1.125 139.68 12.75 10.5
    12" 160 1.312 160.27 12.75 10.126
    Pipe Size Schedule Wall Thickness Weight/ft OD ID
    14" 30/STD 0.375 54.57 14 13.25
    14" 40 0.438 63.37 14 13.124
    14" XH 0.5 72.09 14 13
    14" 60 0.594 84.91 14 12.812
    14" 80 0.75 106.13 14 12.5
    14" 120 1.094 150.79 14 11.812
    14" 140 1.25 170.22 14 11.5
    14" 160 1.406 189.11 14 11.188
    16" 30/STD 0.375 62.58 16 15.25
    16" 40/XH 0.5 82.77 16 15
    16" 60 0.656 107.5 16 14.688
    16" 80 0.844 136.62 16 14.312
    16" 100 1.031 164.82 16 13.938
    16" 120 1.219 192.43 16 13.562
    16" 140 1.438 223.64 16 13.124
    16" 160 1.594 245.25 16 12.812
    Pipe Size Schedule Wall Thickness Weight/ft OD ID
    18" STD 0.375 70.59 18 17.25
    18" 30 0.438 82.06 18 17.124
    18" XH 0.5 93.45 18 17
    18" 40 0.562 104.8 18 16.876
    18" 60 0.75 138.17 18 16.5
    18" 80 0.938 170.92 18 16.124
    18" 100 1.156 207.96 18 15.688
    18" 120 1.375 244.14 18 15.25
    18" 140 1.562 274.22 18 14.876
    18" 160 1.781 308.5 18 14.438
    20" 20/STD 0.375 78.6 20 19.25
    20" 30/XH 0.5 104.1 20 19
    20" 40 0.594 122.9 20 18.812
    20" 60 0.812 166.4 20 18.376
    20" 80 1.031 208.87 20 17.938
    20" 100 1.281 256.1 20 17.438
    20" 120 1.5 296.37 20 17
    20" 140 1.75 341.1 20 16.5
    20" 160 1.969 379.1 20 16.062
    Pipe Size Schedule Wall Thickness Weight/ft OD ID
    22" 20/STD 0.375 86.61 22 21.25
    22" 30/XH 0.5 114.8 22 21
    24" 20/STD 0.375 94.62 24 23.25
    24" XH 0.5 125.5 24 23
    24" 30 0.562 140.8 24 22.876
    24" 60 0.969 238.85 24 22.062
    24" 80 1.219 296.58 24 21.562
    24" 100 1.534 367.39 24 20.932
    24" 120 1.812 429.39 24 20.376
    24" 140 2.062 483.12 24 19.876

    Know more about this product price, catalogue, mill test certificate,  please inquiry to: [email protected]
