Steel Sheet Pile

Steel Sheet Pile

    What is steel sheet piles?
    Steel sheet piles are sections of sheet steel with interlocking edges that are driven into the ground to provide permanent or temporary earth retention and excavation support.

    Production process of steel sheet pile



    Steel sheet piles are divided into hot rolled and  cold formed precision sheet piles.

    Hot Rolled Steel Sheet Piles
    Hot rolled steel sheet piles are divided into U-piles and Z-piles.

    U-piles
    U-piles are well-known around the world and have been used in civil engineering projects for over a century:

    The U-pile has several advantages:
    Wide selection of sections,
    Excellent statical properties,
    Highly suitable for re-use and driving into compact soils
    Excellent installation quality and performance.






    Elastic Section Modulus Width Weight Height Back Thickness Web Thickness Back Width Moment of Inertia Coating Area
    Single Pile Wall
    Wᵧ B     h     t Iᵧ A
    cm³/m' mm kg/m kg/m² mm mm mm mm cm⁴/m' m²/m'
    744 600 46,3 77,2 310 7,5 6,4 250,4 11.53 1,60
    775 600 48,5 80,8 310 7,8 6,8 249,3 12.019 1,60
    806 600 51,3 85,5 310 8,0 7,3 248,9 12.499 1,60
    842 600 53,4 89,0 310 8,4 7,6 248,9 13.046 1,60
    877 600 55,4 92,3 310 8,8 7,9 248,9 13.59 1,60
    894 600 56,0 93,3 311 8,9 8,1 248,9 13.905 1,60
    1.138 600 61,5 102,5 320 9,0 8,0 371,2 18.205 1,72
    1.161 600 62,4 104,0 320 9,2 8,1 371,2 18.601 1,73
    1.2 600 64,2 107,0 320 9,6 8,2 371,6 19.199 1,73
    1.241 600 67,8 113,0 320 9,8 9,0 370,2 19.853 1,73
    1.279 600 59,7 99,6 423 9,1 7,3 246,6 27.02 1,82
    1.3 600 72,1 120,2 320 10,0 10,0 361,3 20.93 1,73
    1.404 600 78,6 131,0 322 11,0 11,0 366,9 22.47 1,73
    1.564 600 71,0 118,3 390 9,6 8,8 359,9 30.495 1,85
    1.618 600 73,1 121,8 390 10,0 9,0 359,7 31.548 1,85
    1.672 600 75,2 125,3 390 10,4 9,2 358,1 32.6 1,85
    1.748 600 79,5 132,5 390 10,8 10,0 347,0 34.087 1,85
    1.821 600 76,5 127,5 420 10,7 9,0 347,0 38.243 1,89
    1.954 600 80,2 133,6 421 11,7 9,2 391,0 41.127 1,89
    2.019 600 82,1 136,8 423 12,0 9,5 348,0 42.664 1,89
    2.111 600 85,2 142,0 421 12,8 9,7 348,0 44.435 1,89
    2.068 600 85,7 142,8 420 12,4 10,0 346,3 43.435 1,89
    2.205 600 85,4 142,3 430 13,4 9,0 337,7 47.402 1,90
    2.269 600 86,9 144,0 431 13,9 9,0 337,7 48.893 1,90
    2.506 600 94,1 156,8 434 15,4 9,8 337,7 54.389 1,89
    2.602 600 96,6 161,0 431 16,5 9,5 387,4 56.116 1,90
    2.774 600 102,3 170,5 433 17,5 10,3 339,1 60.112 1,89
    3.211 600 112,4 187,3 457 19,0 10,6 286,9 73.3 1,95
    1.423 500 63,5 127,0 340 11,2 8,7 264,1 24.198 1,56
    1.504 500 66,6 133,2 340 12,0 9,0 264,2 25.575 1,56
    1.602 500 70,3 140,6 340 13,0 9,3 264,5 27.233 1,56
    2.8 500 92,3 184,6 437 18,4 10,5 255,6 61.185 1,73
    1.6 400 62,2 155,5 290 13,0 9,0 249,3 23.206 1,38
    *Coating two sided without the inside of the interlocks

    Z-Piles
    Z-piles are defined by the continuous form of the web and the symmetrical placement of the interlocks on both sides of the neutral axis. This has a very positive effect on the section modulus of the sheet pile.

    Z-piles have the following advantages:
    Highly competitive section modulus/weight ratio,
    Lighter than U-piles when comparing sections with equivalent section modules.
    Increased moment of inertia,
    Wider sections allowing high installation performance and improved water tightness.
    Z-Piles are most commonly supplied and driven as double piles.





    Elastic Section Modulus Width Weight Height Flange Thickness Web Thickness Moment of Inertia Coating Area *
    Single Pile Wall
    Wᵧ B     h t s Iᵧ A
    cm³/m' mm kg/m kg/m² mm mm mm cm⁴/m' m²/m'
    1.675 630 69,8 110,8 374 8,5 8,5 31.3 1,68
    1.735 700 74,0 105,7 420 8,5 8,5 36.36 1,84
    1.805 630 76,0 120,7 375 9,5 9,5 33.86 1,68
    1.805 700 77,4 110,6 420 9,0 9,0 37.89 1,84
    1.935 630 82,2 130,5 376 10,5 10,5 36.41 1,68
    1.875 700 80,8 115,4 421 9,5 9,5 39.42 1,84
    1.94 700 84,2 120,3 421 10,0 10,0 40.94 1,84
    2.005 630 85,4 135,6 377 11,0 11,0 37.73 1,68
    2.01 700 87,6 125,0 422 10,5 10,5 42.47 1,84
    2.324 700 86,6 123,6 458 11,0 9,0 53.219 1,93
    2.435 700 89,5 127,9 459 12,0 9,0 55.87 1,93
    2.517 700 93,1 133,0 460 12,5 9,5 57.828 1,93
    2.6 700 96,7 138,1 460 13,0 10,0 59.81 1,93
    2.682 700 100,3 143,3 461 13,5 10,5 61.78 1,93
    2.765 700 103,9 148,4 461 14,0 11,0 63.75 1,93
    2.932 700 111,1 158,8 462 15,0 12,0 67.735 1,92
    3.58 700 116,2 166,1 509 14,0 11,5 91.13 2,11
    3.69 700 120,2 171,8 510 14,5 12,0 94 2,11
    3.8 700 124,2 177,4 510 15,0 12,5 96.86 2,11
    3.905 700 128,2 183,1 511 15,5 13,0 99.72 2,11
    4.015 700 132,2 188,8 511 16,0 13,5 102.59 2,11
    * Coating two sided without the inside of the interlocks

    Elastic Section Modulus Width Weight Height Flange Thickness Web Thickness Moment of Inertia Coating Area
    Single Pile Wall
    Wᵧ B     h t s Iᵧ A
    cm³/m' mm kg/m kg/m² mm mm mm cm⁴/m' m²/m'
    1.208 700 67,9 97,0 314 8,6 8,5 18.971 1,82
    1.252 770 72,8 94,5 344 8,6 8,5 21.496 1,96
    1.308 700 74,2 105,9 315 9,6 9,5 20.611 1,82
    1.304 770 76,2 99,0 344 9,1 9,0 22.433 1,96
    1.408 700 80,5 114,9 420 10,6 10,5 22.262 1,82
    1.357 770 79,6 103,4 345 9,6 9,5 23.37 1,96
    1.735 700 73,3 104,7 420 8,5 8,4 36.425 1,97
    1.807 700 76,7 109,6 421 9,1 9,0 38.001 1,97
    1.88 700 80,2 114,6 421 9,6 9,5 39.578 1,97
    1.953 700 83,7 119,5 422 10,1 10,0 41.155 1,97
    2.437 700 95,8 136,9 459 11,3 11,2 55.949 2,05
    2.601 700 103,0 147,1 460 12,3 12,2 59.843 2,05
    2.676 700 106,4 152,0 461 12,8 12,7 61.641 2,05
    2.764 700 110,1 157,3 461 13,3 13,2 63.74 2,05
    3.596 700 118,7 169,6 499 15,1 11,2 89.753 2,18
    3.798 700 126,5 180,7 500 16,1 12,2 94.984 2,18
    3.999 700 134,3 191,8 501 17,1 13,2 100.219 2,18
    4.228 700 143,0 204,2 499 18,1 14,0 105.543 2,17
    4.436 700 150,7 215,3 500 19,1 15,0 110.942 2,17
    4.635 700 158,5 226,5 501 20,1 16,0 116.159 2,17
    4.801 580 139,9 241,1 482 19,2 15,1 115.712 2,01
    4.788 700 159,3 227,6 503 22,1 15,0 120.467 2,17
    4.973 700 166,7 238,2 504 23,1 16,0 125.358 2,17
    5.162 700 174,3 249,0 505 24,1 17,0 130.403 2,17
    *Coating two sided without the inside of the interlocks

    Cold Formed Precision Steel Sheet Piles

    Main applications are small retaining walls, temporary and permanent cofferdams with low requirements in water tightness, anchor screens of quay walls, reinforcement of dykes and river embankments.

    Advantages of cold formed and cold rolled sheet piling:
    Less material = lower weight per m²
    Larger effective width = less interlocks
    Fewer sheet piles per wall = Less handling
    Suitable for smaller quantities and projects




    Elastic Section Modulus Width Weight Height Thickness Moment of Inertia
    Single Pile Wall
    Wᵧ B     h t Iᵧ
    cm³/m' mm kg/m kg/m² mm mm cm⁴/m'
    656 850 42,8 50,4 340 5 11.16
    638 800 48,5 62 300 6 9.505
    714 850 51,3 60,6 340 6 12.034
    730 725 45 60,4 300 6 10.727
    846 725 52 71,7 271 7 11.54
    1.245 770 72,6 94 344 8,5 21.43
    1.205 850 44,3 75,3 420 7 24.651
    1.3 770 76,1 99 344 9 22.36
    1.318 850 73,1 86 400 8 26.36
    1.355 770 79,5 103 345 9,5 23.3
    1.73 700 73,1 104,4 420 8,5 36.33
    1.8 700 76,5 109 420 9 37.8
    1.805 850 85,9 101,1 480 9 43.335
    1.944 750 80,9 107,8 460 9 44.718
    1.945 700 83,3 119 421 10 40.95
    2 850 96 112,9 470 10 46.862
    2.43 700 95,7 136,7 459 11,2 55.768
    2.6 700 102,9 147 460 12,2 59.8
    2.76 700 110 157 440 13,2 63.62
    2.8 725 94,9 130,9 550 10 75.965
    3.285 700 76,7 163 500 12 82.929
    3.6 700 118,6 169,4 520 12,5 89.668
    3.71 700 124,5 177,8 499 12,5 92.415
    3.905 700 133 190 560 13,5 97.5
    4.231 750 141,6 188,8 550 13 116.35
    4.6 580 133 229 540 15 110.465
    4.805 750 172,4 229,8 520 15 124.921
    5.02 580 146,8 253 580 16 121.07


    Elastic Section Modulus Width Weight Height Flange Thickness Moment of Inertia Coating Area
    Single Pile Wall
    Wᵧ B     h t Iᵧ A
    cm³/m' mm kg/m kg/m² mm mm cm⁴/m' m²/m'
    264 1.017 40 39,3 160 4 2.128 2,26
    434 1.661 64 38,6 250 4 5.649 2,29
    619 1.54 64 41,6 350 4 10.926 2,47
    448 1.513 72 47,6 205 5 4.608 2,25
    462 1.504 72 47,9 215 5 5.044 2,26
    518 1.651 80 48,2 255 5 7.035 2,3
    619 1.643 80 48,7 300 5 9.747 2,31
    708 1.558 80 51,3 315 5 11.413 2,44
    720 1.365 72 52,7 325 5 11.724 2,49
    781 1.33 72 54,1 360 5 14.118 2,56
    867 1.492 80 53,6 410 5 17.804 2,55
    541 1.51 86,4 57,2 220 6 6.025 2,25
    616 1.477 86,4 58,5 255 6 7.897 2,3
    689 1.443 86,4 59,9 275 6 9.538 2,37
    788 1.38 86,4 62,6 320 6 13.009 2,46
    790 1.55 96 61,9 300 6 12.462 2,45
    835 1.363 86,4 63,4 325 6 13.721 2,49
    973 1.494 96 64,3 360 6 17.715 2,54
    1.052 1.471 96 65,3 410 6 21.609 2,58
    1.149 1.38 96 69,6 425 6 25.317 2,75
    1.245 1.354 96 70,9 425 6 26.474 2,81
    733 1.625 112 68,9 260 7 9.737 2,34
    764 1.415 100,8 71,2 259 7 9.689 2,4
    797 1.425 100,8 70,7 280 7 11.192 2,39
    833 1.6 112 70 280 7 11.976 2,38
    846 1.403 100,8 71,8 290 7 12.29 2,42
    935 1.5 112 74,7 300 7 14.733 2,53
    1.319 1.4 112 80 400 7 26.413 2,71
    1.35 1.385 112 80,9 405 7 27.36 2,74
    1.438 1.351 112 82,9 430 7 30.932 2,81
    512 1.222 96 78,6 160 8 4.105 2,29
    544 1.528 115,2 75,4 170 8 4.636 2,23
    582 1.675 128 76,4 175 8 5.442 2,27
    617 1.186 96 80,9 185 8 5.73 2,36
    848 1.6 128 80 290 8 13.285 2,38
    878 1.375 115,2 83,8 290 8 13.016 2,47
    928 1.568 128 81,6 290 8 13.758 2,42
    956 1.362 115,2 84,7 300 8 14.876 2,5
    978 1.314 115,2 87,7 300 8 16.003 2,59
    1.09 1.54 128 83,1 345 8 18.9 2,47
    1.217 1.489 128 86 325 8 19.814 2,55
    1.31 1.47 128 87,1 360 8 23.62 2,59
    1.492 1.33 128 96,2 400 8 30.953 2,86
    1.607 1.357 128 94,3 425 8 34.315 2,8
    1.805 1.278 128 100,2 450 8 52.106 2,97
    1.225 1.338 129,6 96,9 315 9 19.303 2,54
    1.483 1.43 144 100,7 420 9 33.442 2,66
    1.757 1.352 144 106,5 420 9 37.667 2,81
    1.814 1.346 144 107 425 9 38.577 2,82
    1.922 1.303 144 110,5 430 9 41.339 2,92
    655 1.435 144 100,3 165 10 5.723 2,65
    1.383 993 120 120,8 300 10 21.039 2,82
    1.424 1.525 160 104,9 350 10 24.99 2,49
    2.032 1.34 160 119,4 440 10 44.717 2,84




    Elastic Section Modulus Width Weight Height Thickness Moment of Inertia
    Single Pile Wall
    Wᵧ B     h t Iᵧ
    cm³/m' mm kg/m kg/m² mm mm cm⁴/m'
    302 700 32,4 46,3 150 4 2.209
    374 700 40,4 57,7 152 5 2.753
    455 700 48,5 69,3 154 6 3.369
    540 700 56,3 80,4 156 7 4.004
    600 700 64,2 88,9 158 8 4.46
    680 700 72 102,9 160 9 5.12
    774 710 49,5 69,7 294 5 10.92
    933 710 57,9 82,8 296 6 13.53
    1.08 710 67,3 96,2 298 7 15.701
    1.23 710 76,7 109,6 300 8 17.896
    1.38 710 85,6 122,3 300 9 20.896






    Elastic Section Modulus Width Weight Height Flange Thickness Moment of Inertia Coating Area
    Single Pile Wall
    Wᵧ B     h t Iᵧ A
    cm³/m' mm kg/m kg/m² mm mm cm⁴/m' m²/m'
    1.145  878  80.5  91.7  310  8.6  17.968  2.30
    1.178  878  82.9  94.4  310  8.9  18.504  2.30
    1.257  878  88.8  101.2  310  9.5  19.719  2.30
    1.412  833  80.5  96.7  358  8.6  25.607  2.30
    1.455  833  82.9  99.5  358  8.9  26.391  2.30
    1.554  833  88.8  106.6  358  9.5  28.272  2.30
    1.706  789  82.9  105.1  395  8.9  34.119  2.30
    1.825  789  88.8  112.6  395  9.5  36.580  2.30
    1.976  789  96.1  121.9  395  10.3  39.703  2.30
    1.895  755  82.9  109.8  417  8.9  40.061  2.30
    2.027  755  88.8  117.7  417  9.5  42.957  2.30
    2.194  755  96.1  127.4  417  10.3  46.570  2.30
    2.075  721  82.9  115.0  437  8.9  45.893  2.30
    2.220  721  88.8  123.2  437  9.5  49.162  2.30
    2.403  721  96.1  133.4  437  10.3  53.364  2.30

    Elastic Section Modulus Width Weight Height Thickness Moment of Inertia
    Single Pile Wall
    Wᵧ B     h t Iᵧ
    cm³/m' mm kg/m kg/m² mm mm cm⁴/m'
    605 785 41,9 53,5 276 5 8.395
    724 785 50,4 64,1 277 6 10.053
    836 785 58,4 74,4 278 7 11.657
    951 785 66,6 84,8 279 8 13.302
    1.067 785 74,8 95,3 280 9 14.944
    972 675 41,9 62,6 376 5 18.5
    1.164 675 50,4 74,4 377 6 22.131
    1.35 675 58,4 86,5 378 7 25.698
    1.54 675 66,6 98,7 379 8 29.332
    1.728 675 74,8 110,8 380 9 32.914





    Elastic Section Modulus Width Weight Height Flange Thickness Moment of Inertia Coating Area
    Single Pile Wall
    Wᵧ B     h t Iᵧ A
    cm³/m' mm kg/m kg/m² mm mm cm⁴/m' m²/m'
    471 809 40 49,4 230 5 5.421 2,22
    617 766 40 52,2 270 5 8.338 2,35
    644 766 40 52,2 304 5 9.785 2,35
    784 722 40 55,4 355 5 13.136 2,49
    965 676 40 59,2 425 5 20.516 2,66
    699 792 48 62,7 275 6 9.611 2,27
    783 748 48 64,1 305 6 11.939 2,41
    878 725 48 66,2 325 6 14.265 2,48
    1.153 655 48 73,2 377 6 21.741 2,75
    1.167 659 48 72,8 405 6 23.626 2,73
    1.246 903 60 66,4 470 6 29.28 2,55
    491 794 56 70,5 175 7 4.293 2,27
    532 787 56 71,1 185 7 4.923 2,29
    846 737 56 75,9 275 7 11.628 2,44
    921 727 56 77 306 7 14.095 2,48
    1.078 694 56 80,6 330 7 17.79 2,59
    1.257 665 56 84,3 390 7 24.517 2,71
    1.33 644 56 86,9 378 7 25.13 2,8
    1.201 685 64 93,4 330 8 19.82 2,63
    1.227 683 64 93,6 335 8 20.865 2,64
    1.257 679 64 94,3 350 8 22 2,65
    1.481 639 64 100,1 378 8 28.008 2,82
    1.244 700 72 102,9 314 9 19.527 2,57
    1.307 686 72 105 320 9 20.908 2,62
    1.684 630 72 114,3 375 9 31.568 2,86
    1.735 627 72 114,7 395 9 34.27 2,87
    1.771 882 90 102 450 9 39.857 2,61
    1.832 871 90 103,3 450 9 41.228 2,64
    1.349 682 80 117,2 305 10 20.567 2,64
    1.404 677 80 118,1 320 10 22.468 2,66
    1.72 636 80 125,7 360 10 30.964 2,83
    1.929 607 80 131,7 380 10 36.648 2,97
    2.354 808 100 123,8 475 10 55.898 2,85
    2.468 795 100 125,8 500 10 61.702 2,89
    2.628 776 100 128,9 535 10 70.289 2,96
    3.082 715 100 139,8 575 10 88.594 3,22






    Elastic Section Modulus Width Weight Height Thickness Moment of inertia Coating area*
    Single Pile Wall
    Wᵧ B     h t Iᵧ A
    cm³/m' mm kg/m kg/m² mm mm cm⁴/m' m²/m'
    130 795 24 30,2 120 3 778 2,31
    520 1.17 96 82,1 185 8 4.811 2,39
    940 1.531 128 83,6 325 8 15.291 2,48
    1.202 1.401 128 91,4 440 8 26.457 2,71






    Elastic Section Modulus Width Weight Height Thickness Moment of Inertia
    Single Pile Wall
    Wᵧ B     h t Iᵧ
    cm³/m' mm kg/m kg/m² mm mm cm⁴/m'
    182 600 62,5 37,5 78 6 726
    242 600 83,3 50 80 8 968





Know more about this product price, catalogue, mill test certificate,  please inquiry to: sales@nan-steel.com

Contact

We use cookies to offer a better browsing experience, analyze site traffic, and personalize content. By using this site, you agree to our use of cookies.

Accept
Decline
